VPN	支持VPN
品牌	Cisco/思科
型號	ASA5525-IPS-K9

CISCO  ASA5525-IPS-K9

思科Cisco ASA 5525-X IPS Edition (ASA5525-IPS-K9)防火墻

Cisco ASA 5500 series adaptive security appliance fits your network and budget while offering the same proven level of security that protects some of the largest networks at some of the most security-conscious companies in the world. The ASA 5500 series scales to meet the performance and security requirements of a wide range of network applications, to correspond with your changing needs.



The Cisco ASA 5525-X is midrange security appliance that uses the Cisco SecureX framework for a context-aware approach to security that delivers multiple security services, multigigabit performance, flexible interface options, and redundant power supplies. It is built on the same proven security platform as the rest of the ASA family of security appliances, and has been designed to deliver superior performance for exceptional operational efficiency.

   Product Details

Device Type	Security appliance
Enclosure Type	Rack-mountable - 1U
Dimensions (WxDxH)	42.9 cm x 39.5 cm x 4.24 cm
Weight	6.77 kg
RAM Installed ( Max )	12 GB
Ports Qty	8
Data link Protocol	Gigabit Ethernet
Network / Transport Protocol	IPSec
Performance	Firewall throughput : 2 Gbps VPN throughput (3DES/AES) : 300 Mbps Connection rate : 20000 connections per second Firewall + intrusion prevention throughput : 600 Mbps
Capacity	IPSec VPN peers : 750 SSL VPN peers : 2 Concurrent sessions : 500000 Virtual interfaces (VLANs) : 200 Security contexts : 2
Power	AC 120/230 V ( 50/60 Hz )
Manufacturer Warranty	90 days warranty

 GeneralProcessor / Memory / StorageNetworkingExpansion / ConnectivityMiscellaneousPowerSoftware / System RequirementsManufacturer WarrantyEnvironmental Parameters

Device Type	Security appliance
Height (Rack Units)	1U
Width	42.9 cm
Depth	39.5 cm
Height	4.24 cm
Weight	6.77 kg
RAM Installed ( Max )	12 GB
Hard Drive	None.
Form Factor	Rack-mountable
Ports Qty	8
Connectivity Technology	Wired
Data link Protocol	Gigabit Ethernet
Network / Transport Protocol	IPSec
Performance	Firewall throughput : 2 Gbps VPN throughput (3DES/AES) : 300 Mbps Connection rate : 20000 connections per second Firewall + intrusion prevention throughput : 600 Mbps
Capacity	IPSec VPN peers : 750 SSL VPN peers : 2 Concurrent sessions : 500000 Virtual interfaces (VLANs) : 200 Security contexts : 2
Status Indicators	Power, Boot State, HDD activity, active, alarm, VPN
Features	Firewall protection, VPN support, VLAN support, High Availability, Intrusion Prevention System (IPS)
Encryption Algorithm	DES, Triple DES, AES
Expansion Slot(s)	1 (total) / 1 (free) x Expansion Slot
Interfaces	8 x network - Ethernet 1000base-T - RJ-45 1 x management - Ethernet 1000base-T - RJ-45 1 x management - console - RJ-45 2 x Hi-Speed USB - 4 PIN USB Type A
Rack Mounting Kit	Included
Compliant Standards	C-Tick, EN 61000-3-2, ICES-003, EN 61000-3-3, EN55024, EN55022 Class A, CISPR 22, EMC, EN 60950-1, UL 60950-1 Second Edition, FCC Part 15 B Class A, VCCI V-3, KC, IEC 60950-1 Second Edition, CSA C22.2 No. 60950-1-07 Second Edition
Power Device	Power supply - internal
Voltage Required	AC 120/230 V ( 50/60 Hz )
Software Included	Cisco VPN Client, Cisco AnyConnect Client
Service & Support	90 days warranty
Service & Support Details	Limited warranty - advance parts replacement - 90 days - response time: 10 days
Min Operating Temperature	-5 °C
Max Operating Temperature	40 °C
Humidity Range Operating	0 - 90%
